Double head film blowing machine

Double Head FilmBlowingMachine High speed, low consumption and energe saving,even and smooth film are the most outstanding characteristics of this machine. SpecificationModel SJ50×28 -FMS500×2 SJ55×30 -FMS600×2 Screw Diameter(mm) 55 55 Screw Ratio(L/D) 30:1 30:1 Heater Capacity(kw) 11 11 Driving Motor Power (kw) 15 18.5 Temperature Controller Panel(zone) 12 12 Roller With (mm) 150×500×2 150×600×2 Take-up Power(kw) 0.55×2 0.55×2 Take-up Speed (max.m/min) 20-75 20-75 Die Diameter(mm) 30-70 30-80 Air Blower Power (kw) 2.2×2 2.2×2 Width of Film (mm) 80-400 160-500 Effective Film Width (mm) 0.02-0.10 0.02-0.10 Extrusion Outputkg/h) 50 55 Assembling Dimension (L×W×H m) 5×2.8×3.8 5×3x4 All these technical parameters can be varied with customers’ request. No further notifice for any variation.
